FEATURES

  • Low-cost: The MP-400 offers many clever functions, but thanks to its smart design it is by far the cheapest robot in the range.

  • Splash-proof: The outer shell made of impact-resistant Glass Fiber Reinforced Polymer can be mounted in seconds and offers reliable protection against splashing water.

  • Agile:  Thanks to the central differential drive and compact dimensions, the MP-400 fits through even the smallest gaps.

  • Easy maintenance: The tool-less opening cover allows direct access to all internal components, while the modular design guarantees simple modifications and the shortest possible maintenance time.



In addition, we offer many interesting options.

TECHNICAL DATA

Dimensions & Weights

Payload
Default 100 kg, high payload 150 kg

Dimensions (in mm)
590 x 559 x 411 (LxWxH)

Speed
<1,5 m/s

Uptime
up to 10 h or up to 8 km

Components

Sensors
1 x 2D laser scanner or 6 x ultrasonic sensors (opt.)



Dimensioned drawing

3D View

Media

The MP-400 is ideally suited as the basis for a driverless transport system.



Configure your robot

MP-400
Basic configuration
Description
Turnkey system: 2x motors, 1x Sick S300 expert scanner, sealed lead battery 24V/50Ah, wireless joystick, manual charger, on-board computer (Intel i5, 8 GB RAM, >200 GB SSD, WLAN), ROS, documentation, CE conformity declaration

1 day training
Description
In Heilbronn for up to 3 persons
inclusive catering

Basic Support
Description
3 months support (telephone/e-mail)

Quick battery change system

Automatic charging station

High payload option
Description
Load capacity increased to 150 kg

IOBoard

i7 on-board computer
Description
Intel Core i7, 16 GB RAM, 400+ GB SSD

Ultrasonic sensors

Extended support
Description
Additional 6 months support
by telephone/e-mail/update
